Hattersley 973G PN16 Double Regulating Valve - Gearbox Operated

Typical lead time is 3 to 5 working days. We'll contact you if this changes.

Description

Fig. 973G Ductile Iron with Double Regulating Feature Balancing Valve - Static - Gearbox Operated

Features & Benefits
• Robust iron body materials for long service life
• Precise flow regulation
• Fully-lugged – easy to install and operate
• Positive flow control at all settings
• Available in sizes 50mm to 600mm

Material Specification

• Ductile Iron

Pressure/Temperature Rating

•EPDM Seat
•16 bar from -10 up to 120ºC

Service Application

•Suitable for Chilled Water, LTHW and MTHW

Test Pressures

• Shell: 24 bar
• Seat: 17.6 bar

Specification

• Generally conforms to BS EN 593: 2009
• All operators fitted with double regulating feature

Note

• Butterfly valves should not be less than
• 30° open when used for regulation duties

Datasheet

Hattersley 973G PN16 Double Regulating Valve - Gearbox Operated Datasheet
